New Lens Mount FFD and ID Chart

_dsc4775-2-forman

Ove Bengtsson, Product Manager at Hasselblad, said it’s not everyday that someone shows up at a trade show booth with micrometer in hand. Photo: Mark Forman.

At PhotoPlus Expo yesterday, cameras with missing specs were measured and the Lens Mount FFD and ID Chart has been updated.



Mount Flange Focal Depth (FFD) Inside Diameter of Mount
Fujifilm X-series 17.7 mm
Sony E-mount 18mm 46.1 mm
Canon EOS M-Mount 18mm 47 mm
Hasselblad XCD 18.3 mm ~61 mm
Sony FZ mount (on F55/F5) 19 mm ~84 mm
MFT (Micro Four Thirds) 19.25 mm ~38 mm
Leica SL 20 mm  ~51 mm
Fujifilm GX Medium Format 26.7 mm ~65 mm
Leica M 27.8 44 mm
Panavision SP 70 (Primo 70) 40 mm ~66 mm
Canon EF 44 mm 54 mm
Nikon F 46.5 mm 44 mm
Leica R 47 mm 49 mm
Éclair CA-1 bayonet 48 mm 46 mm
ARRI PL 52 mm 54 mm
Leica S 53 mm  ~66 mm
Panavision PV 57.15 mm 49.50 mm
ARRI XPL (Alexa 65) 60 mm 72 mm
Hasselblad H 61.63 mm  ~67 mm
Mitchell BNCR 61.468 mm 68 mm
ARRI Maxi PL (765) 73.5 mm 64 mm
Hasselblad 500/2000 74.9 mm 69 mm
